Wireharness - Babetta134, Stella (Standart)

Full specifications

Wireharness - Babetta 134, Stella (Standart)

Note: Complete wiring designed for Babetta 134 Stella with STANDARD thyristor (ie thyristor + induction coil). All connectors are already pressed by machine, all cables have a length reserve, you don't have to do anything - just plug it in.

• the wiring is suitable for both round and square front lights, the push-in connectors of the front light are with tongues, if you use a square light, you slide the connectors into the terminal block that is part of the wiring and connect this terminal block to the output from the square light, if you use a round front light lights, the connectors connect directly to the bulb socket

• wiring is including front and rear brake switch wiring

Can be used for:

• Babetta type 134

Note: We are not responsible for incorrect assembly, possibly for non-functional parts of the electronic system caused by improper installation.
